- Single (UP) 3rd Gen. Intel® Xeon® Scalable Processor
- 8-Channel RDIMM/LRDIMM DDR4 per processor, 16 x DIMMs
- Supports Intel® Optane™ DC Persistent Memory
- Intel® C621A Express Chipset
- 2 x 10Gb/s BASE-T LAN ports (Intel® X710-AT2)
- 1 x dedicated management port
- 24 x 3.5″ SATA/SAS hot-swap HDD/ SSD bays
- 2 x 2.5″ SATA hot-swap SSD bays for booting device
- Mini-SAS HD, SFF-8643 (12Gb/s Supported)
- 7 x PCIe Gen4 x16 expansion slots
- Aspeed® AST2500 remote management controller
- Dual 1200W 80 PLUS Platinum redundant power supply
- Optimized performance with Mellanox Infiniband EDR and Ethernet 100G products
Where Compute Reigns
3rd Gen Intel® Xeon® Scalable Processors – “Ice Lake”
GIGABYTE servers and Intel Xeon Scalable Processors deliver incredible 1P/2P performance from edge to data center with incredible gains in I/O throughput and workload demands that need high performing CPUs with large, yet optimized, memory configurations.
- Enhanced I/0: Support for PCIe 4.0 allows for double the throughput of PCIe 3.0 for fast and large data transfers. Also, 64 lanes per socket with up to 128 lanes in a 2P configuration for fast data transmission from CPU to GPU, accelerator or storage.
- CPU Performance Boost: Now up to 40 cores per socket with greatly improved IPC on Intel’s 10nm architecture while operating CPUs at 105-270W. Also, an additional UPI lane is added for up to 11.2GT/s for a low latency interconnect between CPUs.
- Next Gen Memory: Each processor provides eight memory channels to support 8 or 16 DIMM slots with up to DDR4-3200. There are two sub-clustering modes, Sub NUMA (SNC) and Hemisphere (HEMI), available using balanced memory that results in performance improvements. Additionally, support for Intel Optane PMem 200 series provides two modes for greater memory capacity and data persistence to process large amounts of data faster.
- Next Level Security: New instructions and architecture deliver a high level of cryptographic operations for data privacy and protection. Cryptographic accelerators speed up encryption protocols as well as improvements in software guard extensions and memory encryption are added.
- AI Acceleration: AI inference and training are enhanced with DL Boost Technology for greater business, operational, and security insights. Applications include HPC, AI, and Media & Graphics.
Intel® Xeon® W-3300 Processors
The Intel® Xeon® W-3300 processors are optimized for advanced workstation professionals in a single socket solution. These processors are designed for heavily threaded, I/O intensive workloads across Architecture, Engineering, and Construction (AEC), Media and Entertainment (M&E), and Artificial Intelligence/ Machine Learning (AI & ML).
| Intel® AVX-512 | Up to 38 Cores | Up to 76 Threads | Up to 4.0 GHz Turbo | Intel® Deep Learning Boost | Up to 4TB Memory Capacity |
|---|---|---|---|---|---|
| WORKLOAD ACCELERATIONS | CORE AND THREAD COUNT | BASE AND TURBO FREQUENCY | AI DEVELOPMENT | 8-Memory Channels | |
| WHEN IT MATTERS | WHEN IT MATTERS | WHEN IT MATTERS | WHEN IT MATTERS | WHEN IT MATTERS | |
| DATA SCIENCE NumPy, SciPy, Pandas, Scikit learn, XGBoost , Modin , Omnisci , daal4py, Tensorflow, PyTorch |
|||||
| MACHINE LEARNING | MACHINE LEARNING (INFERENCE) Scikit-learn, XGBoost, daal4py, OpenVINO™ |
||||
| MACHINE LEARNING (TRAINING) Scikit-learn, XGBoost, daal4py |
|||||
| DEEP LEARNING Kaldi, MXNet, ONNX, TensorFlow, OpenVINO™, PyTorch |
|||||
MU92-TU0 Product Overview
MU92-TU0 Motherboard Block Diagram
4U Rackmount Middle Depth Storage Server Chassis
．Supports up to SSI EEB/EATX form factor motherboards
．4U 24x Hot-swappable 2.5” or 3.5” drive bays
．Hot-swappable fan modules
．12Gb/s Mini-SAS HD backplane supporting SAS 3.0 & SATA 3 drives
．1200W 1+1 CRPS Redundant Power Supply (80+ Platinum)
